Product Description
Name |
BNC Straight PCB Jack |
Model |
XMR020 |
Body Finish |
Nickel |
Body Material |
Brass |
Cable Type |
Not Applicable |
Contact Finish |
gold |
Contact Material |
Phosphor Bronze |
Contact Termination |
Solder |
Coupling Mechanism |
Bayonet |
Frequency (Max GHz) |
4 |
Gender |
Jack |
Impedance (Ohms) |
75 |
Insulator Material |
PCTFE |
Orientation |
Straight |
Ports |
1 (Single Port) |
Temp (Max Degrees Celsius) |
85 |
Temp (Min Degrees Celsius) |
-40 |
Termination Style |
PCB - Through Hole |
