Product Description
Name | Connectors for Flexible Cable |
Model | XMRL291 |
Body Finish | White Bronze |
Body Material | Brass |
Contact Finish | Gold |
Contact Material | Brass |
Frequency (Max GHz) | 7.5 |
Gender | Plug |
Impedance (Ohms) | 50 |
Insulator Material | PTFE |
Orientation | Straight |
Panel Mounting Feature | Not Applicable |
Power (Max Watts) | 1 |
Temp (Max Degrees Celsius) | 165 |
Temp (Min Degrees Celsius) | -65 |
Thread Direction | Standard |
