Product Description
Name |
SMA Straight Solder Plug 50 Ohm |
Model |
XMRSMA6 |
Body Finish |
Gold |
Body Material |
Brass |
Contact Finish |
Gold |
Contact Material |
Brass |
Contact Termination |
Solder |
Coupling Mechanism |
Threaded |
Frequency (Max GHz) |
18 |
Gender |
Plug |
Impedance (Ohms) |
50 |
Insulator Material |
PCTFE |
Orientation |
Straight |
Panel Mounting Feature |
Not Applicable |
Ports |
1 (Single Port) |
Temp (Max Degrees Celsius) |
165 |
Temp (Min Degrees Celsius) |
-65 |
Termination Style |
Cable - Solder |
Thread Direction |
Standard |
