SMB-JFB2
XIAO MA
XMRSMB2
086 semirigid 086 semiflexible RG405 ZLC260
| Quantity: | |
|---|---|
Product Description
Name | SMB Jack 086 semirigid 086 semiflexible RG405 ZLC260 |
Model | XMRSMB2 |
Body Finish | Gold |
Body Material | Brass |
Contact Finish | Gold |
Contact Material | Brass |
Contact Termination | Solder |
Coupling Mechanism | Push-on |
Frequency (Max GHz) | 4 |
Gender | Jack |
Impedance (Ohms) | 50 |
Insulator Material | PCTFE |
Orientation | Straight |
Panel Mounting Feature | Mount |
Temp (Max Degrees Celsius) | 165 |
Temp (Min Degrees Celsius) | -65 |
Thread Direction | Standard |
